Visual Tutorial: Sheet optimization using the sheet wizard
The sheet wizard is a tool that carries out a
cost-benefit analysis of each sheet format you choose for a layout and
the number of pieces you want to produce. It shows the number of sheets
that will be needed, the layout 1ups per sheet, the total output, the
waste area, and the waste area percentage for each sheet format.
In this video we set the sheet size and
margins.
Visual Tutorial: Sheet Optimization
Click the icon to watch the
video. Run time: 0:54 min.
PROCEDURAL STEPS
Open the layout drawing.
On the Layout toolbar, click
Apply Layout Template to New Sheet.
In the Apply Layout
Template to New Sheet dialog box that appears, click Opt. Sheet.
In the Optimal Sheet
Selection: Input dialog box that appears, enter the number
of pieces you want to produce — in this case: 100,000.
In the list select and add all the sheet formats
you want analyzed (in our case: all standard sheet formats in Landscape
orientation), and then click Next.
Click Next.
In the Optimal Sheet
Selection: Result dialog box that appears, select the optimal
sheet format from the table.
Click the icon to watch the
video. Run time: 0:54 min.
.
